Project description and technology
The design of the garage consists of four copies and includes architectural, structural, internal electrical and sanitary installation parts.
The project includes a basic list of steel, wood and window and door joinery.
The project is accompanied by a free approval of the introduction of changes, a statement of the designers on the execution of the project in accordance with applicable standards and regulations, as well as photocopies of the authorizations of the designers with a current entry in the chamber.
– External walls: 4×15 posts spaced max.
every 40cm upholstered outside with OSB 3 1.2cm , and inside with GKF 1.25cm , the space between the posts filled with mineral wool 15cm.
– 30° mono-pitched roof – wooden roof trusses in a mixed rafter and lattice system.
In the projects we recommend: Porotherm, Koramic, Terca products from Wienerberger; Hörmann gates, drives and doors ; VELUX skylight windows; TermoOrganika insulation systems ; Viessmann heating systems. For details on individual partitions, see the Technology entry Each of the 6 copies (3 architectural-construction projects and 3 technical projects) of the set of architectural-construction documentation with trades ordered from us is sealed. You can find more information about seals here – Why do we seal the documentation? To make sure that the project fits the development conditions of your plot or the guidelines of the local plan, order detailed drawings (under the projection) and present them to the local adaptive designer (you can use the help of our representatives).
Ground plan
| No. | Name | Pow. usable [m²] |
Pow. net [m²] |
|---|---|---|---|
| 1. | Garage | 36.63 | 0 |
| 2. | Pom. Utility |
9.6 | 0 |
| 3. | WC | 2.35 | 0 |
| 4. | Gazebo | 22.31 | 0 |
| Total | 70.89 | 0 |
